Description
“Drew’s” Hydraulic Throw Out Bearing CSC (Concentric Slave Cylinder) – Standard Clutch use 82870 with a Flat Face Bearing, includes 10x Shims and holding bolts. Unit compressed height is (1.688”) 42.8mm to a max of (2.375″) 60.3mm giving a max 17.4mm of travel for free-play and release.
These will work with most American Transmissions like Muncie, Jerico, Saginaw and T10 with 35mm (1.379”) bearing retainer sleave size. can also be
used on some Japanese Transmissions such as Toyota W55, W56, W57, W58, R150, R151, Nissan Rb20, Rb20det, Rb25, Rb25det, Rb30, these units do
come standard with a “FLAT” face release bearing – to be used on a rolled diaphragm pressure plate, but we can swap to a round face bearing- to use with a flat
diaphragm pressure plate if needed
